Eliminate Wi-Fi Dead Zones:Extend the range of existing 802.11b/g/n Wi-Fi
Smart 3-in-1 modes:Access Point, Wi-Fi Extender or Wi-Fi Bridge
Smart iQ Setup:Smartphone, tablet or web-browser setup with no CD or computer required
Smart App Control and Analytics:
Free EdiRange app with Wi-Fi analytics, scheduling and guest network
Green Wi-Fi Power Switch:
Switch between normal green Wi-Fi power and turn off when not in use
Cross-Band Technology for Maximum Speed:
Data is transmitted on one band and received on the other band, a faster network with better performance.
Signal Strength LED Indicator:
Finds the best location for optimal Wi-Fi coverage
Wi-Fi Scheduling:Program intelligent schedules to manage your Wi-Fi
Frequency Band
2.4GHz
5GHz
Wireless Standards and Data Rates
IEEE 802.11ac (up to 433Mbps)
IEEE 802.11n (up to 300Mbps)
IEEE 802.11a (up to 54Mbps)
IEEE 802.11g (up to 54Mbps)
IEEE 802.11b (up to 11Mbps)
Hardware Interface
1 x 10/100Mbps Ethernet LAN port
1 x Slide switch
1 x WPS button
LEDs: 5GHz, 2.4GHz, Signal indicator, Wireless, Power, WPS, LAN
1 x AC plug (EU, UK, US, or AU)
Management
16-language user interface
gradable firmware
Security
64/128-bit WEP, WPA-PSK and WPA2-PSK encryption
802.1x authentication, User access control (in access point mode)
WPS (Wi-Fi Protected Setup)
System Requirements
Existing wireless home network (2.4GHz/5GHz) for Wi-Fi extender/Wi-Fi bridge mode, or cable/DSL modem router for access point mode
Computer with IEEE802.11ac/a/b/g/n Wi-Fi capability and web browser for software configuration (Internet Explorer, Google Chrome, Firefox, Opera or Safari latest version)
iOS 6 above or Android 4.x above for mobile app
Installation
Multi-language iQ Setup (browser interface)
Hardware WPS button
Antenna
3 x internal antennas (2.4GHz x 2, 5GHz x 1)
Power Adapter
Built in AC100-240V, 0.16A 50-60Hz power module
Item Dimension (L"xW"xH")
8 x 6 x 4
Weight
2 lb
Warranty Information
2 years
