1/3" progressive scan CMOS

?Up to 2560 x 1440@25fps resolution

?Min. illumination:

Color: 0.005 Lux @(F1.6, AGC ON)

B/W: 0.001 Lux @(F1.6, AGC ON)

0 Lux with IR

?4x optical zoom, 16x digital zoom

?120 dB WDR, 3D DNR, HLC, EIS, Regional Exposure, Regional Focus

?12 VDC and PoE

?Up to 20 m IR distance

?IK10, IP66

?Support H.265+/H.265 video compression

Camera
- Image Sensor:
1/3" progressive scan CMOS
- Effective Pixels:
2560(H)x1440(V)
- Signal System:
PAL/NTSC
- Minimum Illumination:
Color: 0.005 Lux at (F1.6, AGC ON)
B/W: 0.001 Lux at (F1.6, AGC ON)
0 Lux with IR
- White Balance:
Auto/Manual/ATW (Auto-Tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp
- AGC:
Auto/Manual
- HLC:
Support
- WDR:
120dB
- Shutter Time:
50Hz: 1/1 s to 1/30,000 s
60Hz: 1/1 s to 1/30,000 s
- Day and Night:
ICR
- Digital Zoom:
16x
- Privacy Masking:
24 privacy masks programmable
- Auto Focus:
Auto / Semi-automatic / Manual

Lens
- Focal Length:
2.8 to 12mm, 4x optical zoom
- Zoom Speed:
Approx. 2s (optical lens, wide-tele)
- Angle of View:
Horizontal field of view: 100^o to 33^o (Wide-Tele)
Vertical field of view: 53^o to 18^o (Wide-Tele)
Diagonal field of view: 119^o to 37.5^o (Wide-Tele)
- Minimum Working Distance:
10 to 1500mm (wide-tele)
- Aperture Range:
F1.6 to F2.7

Pan and Tilt
- Pan Range:
0^o to 330^o
- Pan Speed:
Configurable, from 0.1^o/s to 100^o/s,
Preset speed: 100^o/s
- Tilt Range:
Tilt: 0^o to 90^o
- Tilt Speed:
Configurable, from 0.1^o/s to 100^o/s
Preset Speed: 100^o/s
- Proportional Zoom:
Rotation speed can be adjusted automatically according to zoom multiples
- Number of Preset:
300
- Power-off Memory:
Support

Infrared
- IR irradiation distance:
20m
- IR irradiation angle:
Adjustable by zoom

Input and Output
- Audio Input:
1-ch audio input
- Audio Output:
1-ch audio output

Network
- Ethernet:
10Base -T, /100Base-TX, RJ45 Connector
- Max.Image Resolution:
2560 x 1440
- Main Stream:
50Hz: 25fps (2560 x 1440, 2048 x 1536, 1920 x 1080, 1280 x 960, 1280 x 720)
60Hz: 24fps (2560 x 1440), 30fps (2048 x 1536, 1920 x 1080, 1280 x 960, 1280 x 720)
- Sub Stream:
50Hz: 25fps(704x576, 640x480,352x288)
60Hz: 30fps(704x480, 640x480,352x240)
- Third Stream:
50Hz: 25fps (1280 x 720, 704 x 576, 640 x 480, 352 x 288)
60Hz: 30fps (1280 x 720, 704 x 480, 640 x 480, 352 x 240)
- Video Compression:
Main Stream: H.265+/H.265/H.264+/H.264
Sub-Stream: H.265/H.264/MJPEG
Third Stream: H.265/H.264/MJPEG
- ROI encoding:
Support 2 areas with adjustable levels
- Audio Compression:
G.711ulaw/G.711alaw/G.726/MP2L2/G.722
- Audio Mode:
OFF/Audio input/Audio output
- Protocols:
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
- No. of Simultaneous Users:
Up to 20 users
- Three-Stream:
Support
- Mini SD Card:
Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB
- User/Host Level:
Up to 32 users, 3 levels: Administrator, Operator and User
- Security Measures:
User Authentication (User ID and Password), Host Authentication (MAC address), HTTPS Encryption, IEEE 802.1x Port-Based Network Access control, IP address Filtering
- Hik-Connect:
Support

General
- Power Supply:
12 VDC and PoE
- Power Consumption:
Max.: 12 W (Max. 3.9 W for IR)
- Working Temperature/Humidity:
-20^oC to 60^oC (-4^oF to 140^oF)
- Protection Level:
IP66 Standard, IK10, TVS 4000V Lightning Protection, Surge Protection and Voltage Transient Protection
- Material:
Aluminum alloy, PC, PC+ABS

Item Dimension (L inchxW inchxH inch)
7 x 6 x 6
Weight
2.00lb
