o Up to 1900 Mbps, 802.11ac(1300Mbps over 5GHz) + 802.11n(600Mbps over 2.4GHz). Broadcom Turbo-QAM technology increases wireless-N data rate to 600 Mbps for 33% faster performance.
o Five Gigabit ports,speed 10/100/1000 Mbps,1x Gigabit WAN port, 4x Gigabit LAN ports.
o Dual-core processor for fast and responsive performance with Wi-Fi, Ethernet and USB devices.
o High powered amplifiers and external antennas for whole-home coverage.
o Beamforming+ technology improves the WiFi range and performance.
o 15K Jumbo frame improves the forwarding speed of large data.
o USB 3.0 support Printer Server /Media Server/HDD sharing.
Standard and Protocol
IEEE802.3, IEEE802.3u
Interface
1 x 10/100/1000Mbps WAN port
4 x 10/100/1000Mbps LAN ports
1 x USB3.0 port
Antenna
3 x 3dBi external dual band antennas
Button
1 x Power On/Off button
1 x WiFi on/off
1 x Reset button
1 x WPS button
Power
Input100-240V to 50/60Hz, 0.9A
OutputDC 12V, 2.5A
LED
1 x power, 1 x Internet, LAN, 1 x 2.4G, 1 x 5G, 1 x WPS, 1 x USB
Wireless Standards
IEEE 802.11ac/a/n 5GHz
IEEE 802.11b/g/n 2.4GHz
Data Rate
5GHz: Up to 1300Mbps
2.4GHz: Up to 600Mbps, support Turbo-QAM
Frequency
Simultaneous dual band 2.4 and 5GHz
Transmit Power
CE: less than 20dBm(2.4G) , less than 23dBm(5G)
FCC: less than 30dBm
Basic Features
SSID Broadcast: Enable/Disable
Transmission Power: high, medium, low
Beamforming
wireless Security
WPA-PSK/WPA2-PSK, WPA/WPA2
Wireless Security: Enable/Disable
WPS(WiFi Protected Set-up) fast encryption
Internet Connection Type
PPPoE, Dynamic IP, Static IP
PPPoE(Russia), PPTP(Russia), L2TP(Russia)
Operating Mode
Wireless Router Mode
Universal Repeater Mode
WISP Mode
DHCP Server
DHCP Server
DHCP Client List
DHCP Reservation
Virtual Server
Port Forwarding
DMZ Host
UPnP
Security
Client Filter
Parental Control(support black list and white list)
Remote Web Management
Firewall
Forbid UDP flood attack
Forbid TCP flood attack
Forbid flood attack
Forbid WAN PING from internet
DDNS
Support DynDNS, No-ip, 3322.org, Oray.com, 88ip
USB Sharing
Support Samba(Storage)/FTP Server/Printer Server/ DLNA/ Media Server
